DFA PRODUCT SIMPLIFICATION
DFA Product Simplification software utilizes an intuitive question-and-answer interface that identifies opportunities for substantial cost reduction in a product. By applying industry-tested minimum part count criteria, the software finds parts that can be consolidated/eliminated while maintaining 100% functionality. The outcome of a DFA-based design is a more elegant product that is both functionally efficient and easy to assemble. DFA re-designs also have the added impact of increased quality and reliability, faster development time, and require fewer suppliers.
Benefits of using Design for Assembly software
Product engineers know that 85 percent of manufacturing costs are determined in the early stages of design. When you make informed design decisions during the concept stage, you avoid costly corrections later on. Use DFA software to
Estimate difficulty of assembly.
Support decision making.
Benchmark existing products.
Add focus to design reviews.
Sharpen design skills.
Integrate design and manufacturing.
The Link to Design for Manufacture
DFA complements Design for Manufacture (DFM). Engineers use DFA software to reduce the assembly cost of a product by consolidating parts into elegant and multifunctional designs. DFM software then allows the design engineer quickly to judge the cost of producing the new design and to compare it with the cost of producing the original assembly. Used together, DFM and DFA software gives engineers an early cost profile of product designs, providing a basis for planning and decision making. Such analyses, when performed at the earliest stages of concept design, have the potential to greatly influence manufacturing and other life-cycle costs before the costs are locked in.
DFM CONCURRENT COSTING
DFM Concurrent Costing software provides an immediate, thorough understanding of the primary cost drivers associated with manufacturing your product – and establishes a benchmark for what your product "should cost." Additionally, DFM guides you through an assessment of alternative processes and materials to help you generate various design proposals. Cost results update automatically as you specify tolerances, surface finishes, and other part details. Gradually, as you choose effective shape-forming processes and consider how to modify part features to lower cost, your product becomes cost optimized.
Benefits of using DFM Concurrent Costing software
A Highly Accurate Cost-Estimator
An Easily Implemented Solution
An Aid to Concurrent Engineering
A Useful Design Tool
An Effective Supplier-Negotiating Aid
A Competitive Benchmarking Tool
The Link to Design for Assembly
DFM complements Design for Assembly (DFA). Engineers use DFA to reduce the assembly labor within a product through the consolidation of single function parts into more elegant, multifunctional designs. The DFM software is then used to help the design engineer quickly compare the costs to produce each alternative design. Used together, the DFM and DFA software give engineers an early cost profile for each product design and provide a basis for planning and decision making. Such analyses, when performed at the earliest stages of concept design, have the potential to greatly influence manufacturing and other life cycle costs before they are solidified and become locked in place.
“DFMA is a fundamental business process for the Dell engineering team because it supports our holistic approach to cost. It helps us analyze our designs and make decisions that lower overall costs, not just product costs.”
“Increased manufacturing throughput, reduced damage rates, higher quality, streamlined logistics, and faster delivery are all outcomes of weaving DFMA into the development cycle.”
To view a demonstration of DFA basics, click here
Fully Populated Operations, Machine, and Material Libraries
Cost Breakdown, Cost vs. Life Volume Graphs
Machining Quick Estimator
Compare USA vs. China Manufacturing Costs
On Context Help System
Integrated CAD Support
Harley-Davidson is working with its vendors to reduce costs while allowing the vendor his profit margins. “At the core of our program is the understanding that real savings come from helping suppliers reduce the cost of materials and improve the manufacturability of their designs. The software accurately models part costs, providing a quantitative basis for evaluating competing design alternatives.”
To view a demonstration of DFM basics, click here
